Quick Details

  • Condition: New
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: chengda machine
  • Model Number: KL series 120,150,200,230,260,300,360,400
  • Voltage: 380v
  • Power(W): 2.2kw to 30kw
  • Dimension(L*W*H): 75*32*61 to145*62*115
  • Weight: 100kgs to 660kgs
  • Certification: CE
  • Warranty: 12 monthes
  • After-sales Service Provided: Overseas service center available
  • certification: CE
  • Moisture of raw material: 8%-15%
  • state: Granular
  • Application: Fodder,heating,fertilizer
  • Operation: Simple automatic operation
  • Output: 60-1000kg/h
  • raw material diameter: below 6MM powder
  • colour: blue, red or as your request

Packaging & Delivery

Packaging Details Plywood box
Delivery Time Shipped in 2 days after payment
Specifications

wood and feed  pellet mill

1.CE certificate
2.pellet size: 2.5mm,to 10mm
3.pellet length:60-80cm
4.warranty period :1  years



The advantages of finished pellets:

1.as biomass fuels :(Dia4-10mm,or bigger)

Without dust ,smokeless, Cleanliness.no CO, pollution-free.

High density and heat value, easy burn ,low cost ,convenient use.

2.for animal feed :(dia 2.5 -6mm,or bigger)Taste good ,high-usage



Usage of the machine:



It is used to produce pellet feed for pig, cattle, sheep, rabbit, chicken, duck, fish,etc; or  To make inorganic fertilizer granule

it is also used to produce the wood pellet for fuel.











The requirement of raw material:



  below 6mm powder, if your raw material is straw, wood branch , corn husk and so on, you should grind them into powder at first, and then you can directly use the machine.









Products description:




1. Pellet press can make all kinds of bio-mass material to be solid pellets which is for burning fuel or animal feed.



2. We have new improved models for wood pellet making. Specially design and improved machines according to European standard, with closed house to cover motor, CE electrical parts & insolated protective plate for the electrical panel.



3. Our pellet mill also can process all kinds of sawdust. Paddy Straw, Sunflower Stalk, Forestry Wastes, Wood Chips, Chemical And Many Other Wastes Or Solid Powder Material.



4. Our pellet mill have CE certificate, Which all parts can meet EU standard.






Technical parameter:

Version A are gasoline or diesel engine driven.

Version B are driven by e-motor, without extra cabinet and cover on the motor.

Version C are the first improved models with extra cabinet and closed house on the motor.



As for the die size, you can choose from 2.5mm to 10mm according to your needs.

MODEL NO.

OUTPUT

(kg/h)

POWER

(HP or KW)

SIZE

(cm)

NW/GW

(kg)

Qty/20’FCLRemak

KL120A

90-120

7.5hp

76*43*71

80/100

90

gasoline engine

KL120A100-1308hp87*44*73120/14090diesel engine
KL120B

75-100

2.2kw/220V

75*32*61

80/100

168

CE motor

KL120B75-1003kw/380V75*32*6180/100168CE motor

KL150A

110-210

7.5hp

76*43*71

95/115

84

gasoline engine

KL150A120-2208hp87*46*73120/14084diesel engine
KL150B

150-200

4kw/380V

75*35*65

95/115

126

CE motor

KL200A

250-350

15hp

118*56*95

280/310

40

diesel engine

KL200B

200-300

7.5kw/380V

100*43*95

200/230

60

CE motor

KL200C

200-300

7.5kw/380V

100*46*90

200/230

60

CE motor

KL230A

350-500

22hp

118*56*95

280/310

40

diesel engine

KL230B

350-450

11kw/380V

114*47*97

290/320

45

CE motor

KL230C

350-450

11kw/380V

114*54*93

290/320

45

CE motor

KL260A

300-500

30hp

184*70*116

450/480

16

diesel engine

KL260B400-60015kw/380V120*52*107330/36040CE motor
KL260C400-60015kw/380V122*53*107330/36040CE motor
KL300A600-85055hp200*60*123520/56016diesel engine
KL300B700-80022kw/380V127*52*107410/45030CE motor
KL300C700-80022kw/380V128*58*105410/45030CE motor
KL360A700-95055hp227*62*126600/62016diesel engine
KL360C700-95022hp/380V134*58*106470/50030CE motor
KL400A800-110055hp227*62*126750/78016diesel engine
KL400C800-110030kw/380V145*62*115630/66025

CE motor



First ,thanks for you are interested in our pellet mill .If my TM isn't online ,please send email .We are the reliable supplier,if you want to get good price and quality,please contact us.


 Machine specification in details



















Final pellet packed in the bags for sell.







Load to the container:










Pellet press machine (pellet mill) are our mainly products. We have exported them to many countries around the world many years.
















Factory basic information:



Laizhou chengda machinery co.,ltd was found in 1992 years, mainly produce the flat die feed pellet mill and wood pellet mill.



all the product 90% are export to EU ,USA, AFRICA, And so on.



at the same time , we provide the product for more than  50 trading company in China.



Over view of our factory











Quality Certification :

















Contact information:



Laizhou chengda machinery co.,ltd



TEL:0086-15264530427

E-MAIL: rubyivan19852006( at) gmail.com

skype: rubyivan200612101020

Google talk:rubyivan19852006(at) gmail.com
